pecifications are subject to change without notice
| Frequency Response | 23–22,000 Hz ±3dB |
| Recommended Amplifier Power | 20—1300 watts per channel |
| Horizontal Dispersion | 30° |
| Vertical Dispersion | 48″ (122 cm) line source |
| Sensitivity | 90 dB/2.83 volts/meter |
| Impedance | Nominal: 4 ohms, 0.43 ohms @ 20 kHz. Compatible with 4, 6, or 8 Ohm rated amplifiers. |
| Crossover Frequency | 60, 250–400 Hz |
| High Frequency Transducer | XStat™ CLS™ electrostatic transducer » Panel Dimensions 48″ x 22″ (122 x 56cm) » Radiating Area 1056 in² (6,832 cm² ) |
| Low Frequency Transducer | Rear: 15” (38.1cm) cast basket, high excursion, rigid aluminum cone with extended throw drive assembly. Extensively vented triple shorting ring motor and 4-layer coil to eliminate compression and distortion. Front: 12” (30.5cm) round cast aluminum alloy frame, high excursion, rigid carbon fiber sandwich cone with long throw design, 3-inch (7.5cm) diameter copper-clad aluminum flat wire voice coil, and vented pole piece and under-spider opening to reduce power compression. |
| Cabinet | Phenolic Resin Polymer: Dense substrate with superb mechanical strength to minimize cabinet vibrations caused by woofer cone motion counter forces to provide an ideal baffle for the electrostatic panel and woofers. |
| Components | High-Pass Crossover: 1% resistors mounted to heat sinks, polypropylene capacitors, air core inductors, dual toroidal audio transformers to drive electrostatic element Low-Pass Crossover: 1% resistors mounted to heat sinks, toroidal inductors, supports user options to modify sound output via jumpers. |
| Audio Controls | Bass Control: 0dB, -4dB, -8dB Distance Control: 3 meters (or less), 4 meters, 5 meters (or greater) |
| Inputs | WBT-0705Ag nextgen™ 5-way bi-wire binding posts feature a filigree signal conductor made from fine silver for high conductivity. Fully insulated for CE and IEC conformity providing shock hazard protection. Free from eddy current effects. Max constant current 30 A, admissible peak current 200 A. Outer metal cap with palladium plated finish. |
| Power Draw | Standby: 1W each Max: 15W each |
| Lighting | LED intensity control: On, Dim, Off |
| Weight | 385 lbs. (175 kg) |
| Dimensions | 74.8″ x 30.3″ x 34.2 ” (189.9cm x 76.9cm x 87cm) |
