| Size & weight | |
|---|---|
| Net Weight | 7.05 kg (15.5 lb) |
| Dimensions |
Height: 344 mm (13.6 in) cabinet only Width: 189 mm (7.4 in) cabinet only Depth: 300 mm (11.8 in) cabinet only 328 mm (12.9 in) including grille and terminals |
| Technical Details | |
|---|---|
| Drive Units |
1x ø25mm (1 in) Titanium Dome high-frequency 1x ø165mm (6.5 in) Continuum cone bass / midrange |
| Frequency Range | -6dB 40Hz – 33kHz |
| Harmonic Distortion |
2nd and 3rd harmonics (90dB, 1m on axis) <1% 100Hz – 22kHz <0.5% 150Hz – 12kHz |
| Nominal Impedance | 8Ω (minimum 3.7Ω) |
| Recommended Amplifier Power | 30W – 120W into 8Ω on unclipped programme |
| Technical Features |
Decoupled Double Dome Titanium tweeter Continuum™ cone bass / midrange Flowport™ |
| Description | 2-way vented-box system |
| Max Recommended Cable Impedance | 0.1Ω |
| Frequency Response (+/-3dB from Reference Axis) | 52Hz – 28kHz ±3dB |
| Sensitivity (on axis at 2.83Vrms at 1m) | 88dB |
| Finishes | |
|---|---|
| Cabinet Finishes |
Black White Oak |
| Grille Finishes |
Black (Black) Grey (White and Oak) |
